Roof Mount Horizontal Arrowboard
HW1 Roof mount Horizontal arrow board Including a 90-degree tilt frame for roof mount applications. The easy to use control panel, installed inside the cab, operates the arrow-board display tilt frame & optional Beacons.
An electric actuator tilts the frame. When lowered, the streamlined design allows for low wind resistance, only 215 mm in height when folded 980 mm high in up position.
Sold separately are optional dual flashing amber lights to further promote safety and vehicle visibility.
Features:
- Low profile – only 215 mm high when folded down
- Automatic dimming LED lamps
- High visibility from long distances
- Simple wiring connections between board and controller
- Aluminum black powder coated boards
- Board dimensions 1500 mm wide x 770 mm high
- Complies to AS/NZ Standard AS4192 Illuminated Flashing Arrow Signs, MUTCD Compliance
- Suitable for mounting on trucks and work utes
- Power: 12/24V
- Single Sided configuration featuring 25 individual amber lamps
- IP56 waterproof rating
- Wide range of flashing patterns and flash rates for different applications
- Energy efficient operation with low power dissipation
